At Ariel Rider we're known to make fast, robust, ebikes for any type of adventures. But none of our previous models were as affordable as the Rideal!
We've created a no-BS commuter ebike with the high quality materials and parts we've been using on our other ebikes, so that you can commute in style.
With the help of this high-torque 750W motor and 30-60 mile battery range, you'll be able to tackle hills without breaking a sweat.
Geared Hub Motor
Miles per Charge
Li-ion battery
Payload Capacity
The high-step frame is suitable for most riders between 5'10" - 6'5" (32" standover height, kindly refer to the dimensions at the bottom of this page to make sure of the fit)
The mid-step frame is suitable for most riders between 5'3" - 6'2" (26" standover height, kindly refer to the dimensions at the bottom of this page to make sure of the fit)
48V 14Ah Battery to handle any city commutes with ease on a single charge.
In most cases, you won't need to charge your battery more than twice a week!
While Rideal is a high-performance, stylish electric bike with simple and user-friendly controls.
A powerful 750W motor provides 65 Nm of torque for a smooth, capable ride. Perfect for flattening your everyday hills.
As you'd expect from any Ariel Rider models, Rideal is also equipped with high lumen front lights that allows see and be seen at nights.
Rideal comes with integrated rear lights so you are visible even in the darkest riding conditions.
Rideal is our most affordable ebike ever, but that doesn't mean it's not equipped with great parts. Such as this double walled chain ring to keep your clothes clean.
It just made sense to put the controller there. So when your ebike needs servicing, you can easily reach to the controller.
Shimano 6-Speed drivetrain promises easy riding and low maintenance. Ideal for last-minute trips across campus or zipping around town on an urban adventure.
No matter which PAS mode you're on, the throttle is always at override. Helping you accelerate faster when needed.
27.5 x 1.95 anti puncture tires with reflective sidewalls. Providing very little rolling resistance, providing a longer range.
48V, 14Ah Li-ion battery cells
48V, 2 Amp smart charger, operates on 100V-240V AC power outlets
48V, 750W
Ariel Rider Ebikes custom LED display
750W Geared Hub Motor with 5:1 Planetary Reduction - Japanese Dapu
Headlight: 40 Lux, Seeing distance: 230 ft (70m), Being seen distance: 2+ mi (3,500m)
Taillights: Integrated taillight without brake light indicator functionality
Cadence sensing, crank mounted
25 - 45+ mi
Half-Grip Twist Throttle on right hand side
Water resistant connectors and wiring harness
None
*Due to ongoing supply chain constraints in the e-bike market, components listed are subject to change without prior notification.
All new components have been carefully tested and inspected to ensure they meet, and in most cases exceed, the performance standard of the item we are replacing.
Tektro Aries caliper (MD-M300)
Aluminum alloy comfort grip levers with motor cutoff switch and integrated bell
Sintered metal
Tektro 180 mm front and rear
KMC Z7 Anti-Rust
48T chainring; 170 mm crank length; square-taper J.I.S.; dual-sided chainring guard
Shimano 6-speed
Optional accessory sold separately
Rigid steel fork
Note: Please note that the front fork will be backward when you receive the bike, this is done in order to save from the length of the box.
6061 aluminum
16 tooth freewheel, 16, model: LY-BB16T8VNF
6-speed, 14-28
Durable faux-leather, round
Aluminum swept back handlebar
Semi-integrated 1-1/8", straight steerer
Side mounted
Alloy pedals with reflectors, CrMo axle, standard 9/16" x 20 TPI threading
Optional
Double-wall aluminum, 36 Hole
350 mm x 28.6 mm
Quick release
Thumb shifter
Front 13G/ Rear 12G, Steel, matt black.
60 mm
CST 27.5*1.95 anti puncture with reflective wall.
*Due to ongoing supply chain constraints in the e-bike market, components listed are subject to change without prior notification.
All new components have been carefully tested and inspected to ensure they meet, and in most cases exceed, the performance standard of the item we are replacing.
Mid-Step: 72"
High-Step: 72"
Mid-Step: 5'2" - 6'2"
High-Step: 5'10" - 6'7"
Mid-Step: 33"
High-Step: 37"
Mid-Step: 44"
High-Step: 47"
Mid-Step:
High-Step:
Mid-Step: 24"
High-Step: 33"
Mid-Step: 45"
High-Step: 45"
Mid-Step: 18"
High-Step: 21.5"
Mid-Step: 27"
High-Step: 27"
Mid-Step: 28.6 mm
High-Step: 28.6 mm
Mid-Step: 43"
High-Step: 43"
Mid-Step:
High-Step:
Mid-Step: 27"
High-Step: 27"
Mid-Step:
High-Step:
Mid-Step: 52 lb
High-Step: 52 lb
