Ariel Rider X-Class is selected as Best Fat Tire E-bike of 2020 among other fat tire e-bikes some of which cost more than $3,000.-
X-52V is upgraded version of X-Class.
"Ariel Rider X-Class is selected as Best Fat Tire E-bike of 2020 among other fat tire e-bikes some of which cost more than $3,000.-"
X-52V is upgraded version of X-Class.
"The Ariel Rider X-class 52V is the ultimate affordable electric moped - "
ADVENTURE AWAITS!!!
X-Class was Fast now even Faster
X-Class was designed to be a fast e-bike from day 1. Now thanks to 52V battery system and using massive 35A controller now X-Class 52V is even faster and more powerful.
Did we mention about 1000W motor which is capable of delivering 2000W peak output?
1000W
Geared Hub Motor
Up to 70+
Miles per Charge
52V, 18Ah
Li-ion battery
300 lb
Payload Capacity
What Makes X-Class 52V Unique.
Industry Leading Rear Suspension
Improved tires, two side adjustable front fork and motocross level rear suspension. All is done to improve riding quality on X-Class.
X-Class has one of the best rear suspension in market which is 100% CNC machined for precision. Also it has a rebound adjustment which lets you have;
- - Better Handling
- - Better Support
- - Lower Stance
1000W Motor
We improve motor power and now use a 52V motor. Now using a 1000 Watt motor with improved torque and motor power. New Motor is able to reach 110 Nm torque thanks to our metal gear technology.
| Nominal Power | Peak Power |
1000 Watt |
2000 Watt |
52V System
X-class has a special 1000 Watt Hub Motor. Outside looks same but inside everything is different than other hub motors. Motor is equipped with heavy duty clutch and metal gears which lets our motor to reach torque up to 110 Nm which is definitely industry leader.It will eat hills alive!
When needed X-Class motor can provide peak output of 2000 Watt power.
In order to provide smooth riding and provide enough juice we equipped X-Class with 52V 35 amp controller which has 18 mosfet (transistor). This not only let your controller to provide enough juice but also prevent your controller getting over heated.
52v Long Rage E-bike Battery
Most city commutes are less than 5 miles. Integrated battery has a massive 936 Wh battery pack (52V 18ah) which is good to give 75+ miles per charge. You'll cruise for days and days without charging it.
Our pledge is to provide the highest quality with the greatest design. We will never cut corners on the most important components of your electric bike. This battery has superior capacity and that extra range for you when you need it most. And it only weighs around 7 lbs!
It is securely mounted and can be locked with keys. What makes our batteries special is the safety measures we take so you can safely use your electric bike batteries for long time.
It has massive 90 amp protection board, high and low voltage, current regulators and temperature sensor. This also lets you use your ebike for long duration without any problems.
Why our ebikes are more poweful?
We could choose to use a ready motor from the market but none met our requirements.
So we develop our own patented metal gear technology.
Unlike 99% of other e-bike motors which use nylon gears, we use metal gears. In this way our motors can reach higher torque, speed and power. You can watch a video where we compare our gears with others here.
Got cargo? No Problem
X-Class offers lots of features and you can even turn your X-Class into a utility vehicle by using our rear rack.
If you have a larger cargo then you can get a basket for carrying them on your rear rack.
Want to ride with your friend?
Our Optional Long Saddle is large enough to let two people comfortably ride together.
All X-Class e-bikes are equipped with standard cast iron foot pegs so second passenger can ride safely.
Front and Rear Fenders
Included front and rear fenders made from durable PVC and stainless-steel hardware help protect you from the elements
High Performance Fat Tires
20x4.0 CST Fat Tires on X52 is designed for on and off-road conditions. Did we mention that all are anti-puncture and side reflections to increase visibility.
Integrated Brake Light
Powered using the main battery pack and features brake light functionality that is activated any time the brakes are applied.`
Front Suspension Fork
Customized Motorcycle Grade Fork. We couldn't use any bicycle fork on a power machine like this. We use one of the best forks available which even motorbikes even can use. And they are both adjustable.
Please note that the knobs in the actual production are one red and one black.
7-Speed, 11-42 Tooth Cassette
A wider range of gearing at your disposal means more torque for treacherous uphill climbs and maintain pedal authority at top speed.
LED Headlight
Ariel Rider X-Class is equipped with a Retro Style Large Motorcycle Headlight. Other than looks nothing is Retro about this headlight. It has 2W power with 80 lux lumination which makes it one of the strongest headlight in market now.
Hydraulic Disc Brakes
X-Class is a powerful ebike and we choose the best brakes to handle this power. X-Class has powerful front and rear hydraulic brakes with brake inhibitors.
Tektro is famous for producing hydraulic brakes special for electric bikes. It has a very powerful stopping power.
As hydraulic brakes have closed circuit system, you don't need to worry about cleaning dirt or mud from your brakes.
Both front and rear rotors are 180 mm for having a better stopping power.
ELECTRONICS
-
Battery
- 52V 18Ah battery rated for 800 charges. Battery comes with integrated USB port.
-
Charger
- 52V, 2.5 Amp smart charger, operates on 100V-240V AC power outlets
-
Controllers
- Smart Controller 52V 35ah (Continuous peak current) 18 transistor
-
Display
Backlit LED display with easy diagnostics feature and USB charging port.
-
Hub Motor
-
1000 Watt Nominal, 2000 Watt Peak Motor capable of reaching over 30 Mph speed. Ariel Rider X-Class has highest torque motor in market thanks to metal gears technology.
-
Lights
- Front: Motorcycle style bright headlight
Rear: Integrated taillight with brake light mode.
-
Pedal Assist
- 5 Level Pedal assist with 12 magnet cadence sensor.
-
Range
- 40-75+ Miles,
-
Throttle
Thumb throttle
-
Wiring
- Water resistant connectors and wiring harness
-
USB Ports
- 1 on the screen, 1 on the battery
*Due to ongoing supply chain constraints in the e-bike market, components listed are subject to change without prior notification.
All new components have been carefully tested and inspected to ensure they meet, and in most cases exceed, the performance standard of the item we are replacing.
BIKE COMPONENTS
-
Brakes
- Hyraulic Tektro HD-E 350
-
Brake Rotors
- Tektro 180mm
-
Brake Levers
- Tektro Dorado HDE350 Hydraulic Disc with 160 Rotors, Dual Piston Calipers, Three-Finger Levers with Motor Inhibitors and Adjustable Reach
-
Chain
- KMC Z7
-
Crank Set
- Prowheel, Forged Alloy, 170mm Length, 48 Tooth Steel Chainring with Plastic Guide
-
Derailleur
- Shimano Altus TZ25007428 Derailleur
-
Fender
- Standard
-
Fork
- Motorcycle Level Alloy Heavy Duty Fork, Adjustable
-
Frame
- AL 6061
-
Gearing
- 7 Speed 1x7 Shimano AltusTZ25007428 Derailleur, 14-28 Tooth Cassette
-
Grips
- Durable faux leather
-
Handlebar
- Fork-Handlebar Integrated Aluminum Alloy, 670mm Length
-
Stem
- Promax adjustable stem,
-
Headset
- Neco, Internal Cups, Straight 1-1/8"
-
Kickstand
- Since leg steel, spring loaded, height adjustable
-
Pedals
- Wellgo B087DU Aluminum Alloy Platform
-
Racks
Rear: Optional
-
Rims
- Double Walled, Aluminum Alloy, 28 Hole, 80mm Width.
-
Saddle
- Exclusive Ariel Rider Ebikes moped-style, banana seat (height isn't adjustable). Kindly note that X-Class comes standard with the short saddle, the long saddle is an optional accessory,
-
Shifter
- Shimano AMFLTX50RCT SIS Index Thumb Shifter
-
Spokes
- Stainless Steel, 12 Gauge Rear, Silver with Nipples
-
Tires
-
Wheel Sizes
-
Tire Details
- 5-30 PSI, 0.4 to 2.1 bar, 60tpi casing, wire bead
-
Rear Suspension
- Rebound Adjustable Rear
-
Foot Pegs
Cast iron heavy duty foot pegs
*Due to ongoing supply chain constraints in the e-bike market, components listed are subject to change without prior notification.
All new components have been carefully tested and inspected to ensure they meet, and in most cases exceed, the performance standard of the item we are replacing.
GEOMETRY
FAQ
You can find the most commonly asked questions about the X-52 here.
75+ Miles Range
30+ Mph
52V System
X-Class was Fast now even Faster
X-Class was designed to be a fast e-bike from day 1. Now thanks to 52V battery system and using massive 35A controller now X-Class 52V is even faster and more powerful.
Did we mention about 1000W motor which is capable of delivering 2000W peak output?
Industry Leading Suspension
Improved tires, two side adjustable front fork and motorcross level rear suspension. All is done to improve riding quality on X-Class.
X-Class has one of the best rear suspension in market which is 100% CNC machined for precision. Also it has a rebound adjustment which lets you have;
- Better Handling
- Better Support
- Lower Stance
1000 Watt Motor
We improve motor power and now use a 52V motor. Now using a 1000 Watt motor with improved torque and motor power. New Motor is able to reach 110 Nm torque thanks to our metal gear technology.
| Nominal Power | Peak Power |
1000 Watt |
2000 Watt |
52V System
For most people 48V system provides enough power but for those seeking for the best 52V is what they are looking for.
The higher voltage provides MORE POWER, MORE SPEED, MORE EFFICIENCY AND LONGER RANGE.
X-52V will let you ride for 75+ mile range.
