M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike
M-Class Urban Electric Bike

M-Class Urban Electric Bike

Regular price
Sold out
$1,649.00
Sale price
$1,649.00

FREE Shipping on all ebike orders to the lower 48 states

$200 OFF YOUR PURCHASE when you buy any 2 ebikes with code 200ariel at checkout

*Except Rideal

Quantity must be 1 or more
  • Compact: Easy to store and carry

  • 98 Nm torque mid-drive motor: Offers an incredibly smooth riding experience.

  • 576 Wh (watt-hour) battery: Even at full-throttle, you'll never worry about running out of power.

  • Hydraulic disc brakes (with motor inhibitors): Reliable brake performance on one of the fastest electric commuter bikes on the market.

  • Heavy loading capacity: The optional front basket and rear rack (both optional) lets you carry so much more – groceries, gym bags, and even your children.

2020 Model M-Class Electric Commuter Ebike

Slim in size, huge on performance.
The ultimate urban cycling experience.

You'll love the spirit of Ariel Rider’s M-Class electric commuter bike. Selected as the best small-sized ebike by eBikeReviewer.com in 2018, M-Class is much more than a regular electric folding bike look-alike as it offers the best of every feature needed. This is why M stands for maximum performance at minimum dimensions.

Starved for space at your office or home? Fret not. The M-Class is the best electric commuter bike for anyone who relishes the freedom of cruising when space is at a premium. It’s a smaller ebike, but perfectly suitable for people of all heights, thanks to an adjustable seat post and
handlebar.

M-Class is not only lightweight and compact, it also is the
most powerful among all such compact eBikes (i.e. mostly folding electric bikes). M-Class maximizes your savings, too! Check out this objective comparison of electric bikes costing up to $4,000.


What's New?

New Mid-Drive Motor

We're using a new generation of mid-drive motors with even higher torque than before, to ensure you climb up the hills effortlessly.

For a smoother ride, now M-Class comes with gear sensors, which detect when you're shifting gears and cut off the motor power for a smoother gear change.

Gear Sensor
Brakes with Motor Inhibitors

It's not common to have motor inhibitors on brakes in mid-drive electric bikes, but we're not here to do the common thing. Your safety comes first.

Front Shock Absorbers

Every year we upgrade certain parts on our ebikes according to the feedback we receive from our clients.

The only request we got was the front shock absorbers, so we changed the front forks!

New Display with USB Port

The new screen is not only looking better than the previous one, it also packs a USB port to charge your electronics on the go.

A longer rear rack

The optional rear rack is now larger to carry more stuff with you.

With optional baskets that fit right on the rear rack, you can haul a lot with the new M-Class.


PERFORMANCE

Go the extra mile

Most city commutes are less than 5 miles. We’ve equipped our smallest electric bike with a high-capacity 12 Ah Samsung battery pack.

It's simple to remove, so you can charge it effortlessly at home, office, or anywhere. This compact battery will give you a truly awesome range of 45 to 65 miles per charge. This means you'll cruise for days and days without charging it.

Our pledge is to provide the highest quality with the greatest design. We will never cut corners on the most important components of your electric bike.

This battery has superior capacity for that extra range you when you need it most and it only weighs around 7 lbs!

Astonishing torque

The mid-drive motor offers smooth riding experience - you won't feel like you're riding an electric bike at all.
This mid-drive motors provide one of the highest torque in the market.
M-Class is equipped with the 48V 500W mid-drive motor sporting 98 Nm torque.

Key points:

  • The mid-drive motor increases the torque applied to your rear wheel. This translates to remarkably more power, especially when riding uphill. Compared to hub motors, it's a breeze.
  • Mid-drive motors are very energy-efficient compared to hub motors, so you’ll enjoy far longer-range with a smaller battery.
  • A mid-drive motor is in the middle of the bike, where the crank is located. This way, weight is uniformly distributed and the center of gravity doesn’t change.
  • Unlike other mid-drive options in the market, M-Class is also equipped with a throttle for those longer rides where you don’t want to pedal anymore.

RANGE

45-65+ miles per charge (estimated)

CHARGING TIME

4-6 hours

MAX SPEED

Class 2 Ebike
For details click here.


URBAN COMMUTER

Cargo Capacity

Don't let the size of our M-Class fool you. This bike is an urban workhorse. With the rear rack and optional front basket, you can carry groceries, your gym bag, or even your child all at the same time!

Lightweight

One huge problem we hear about from commuters is weight. Riders are concerned that bikes are too heavy, especially if they live or work in high rise buildings.
We achieve this with advanced frame production techniques, combined with a higher capacity battery using fewer cells.

It'll surprise you how easy it is to lift and carry your M-Class with only hand since it weighs only 47.5 lbs.

Adjustable Stem

The versatile and effective Promax Adjustable Handlebar Stem offers just the right fit. The handlebar stem is adjustable from 90 to 160 degrees and includes spacers for 22.2 and 25.4- millimeter stems. It boasts an alloy for enhanced durability. The seat height also adjusts easily in mere seconds. And did we mention -no tools required! For couples who want to share their ebike, these smart features make quick work of swapping out.

Full Fenders

Not all of us live in sunny SoCal. The M-Class comes equipped with front and rear full coverage fenders to keep you clean and dry if you happen to ride through puddles.



Suspension Seatpost

No city street is a smooth, well-maintained Formula One racetrack. Our adjustable suspension seat post adds yet another level of comfort to your commute, smoothing out those rough roads. At the end of the day, M-Class details like this transform your commute into a gentle breeze.

Maintenance Free 7-Speed Gears

Repairs and maintenance are no fun. We're riders just like you, and we know the struggle. This is why we’ve designed all our ebikes to require minimal maintenance.
The M-Class's Shimano 7-Speed Inner hub gears are extremely durable and highly reliable.
The gears are all hidden inside, protected from the elements and physical damage. Having no external derailleur makes them three times more durable than traditional gears. Learn more about inner hub gears here.

Details

We're confident that Ariel Rider's M-Class is the easiest ebike to move about on, either riding it or walking it.
From top to bottom, M-Class is designed to be extremely easy to carry. An unobtrusive, but very useful handle under the saddle will help you pull your electric bike out of tight spaces, without needing to be right next to it.


SAFETY

Hydraulic Disc Brakes

Tektro Hydraulic Disc Brakes are designed to provide the best brake performance for the fastest ebikes. Be confident of their performance regardless of your speed or weight, and especially going downhill.

LED Headlight

The Spanninga LED headlight ensures that you can see and be seen at night in any road conditions.

This LED headlight is powered by the main battery of the ebike.

Reflective Sidewalls

We want to make sure our riders are visible at all times and from all angles.

That’s why all our tires have reflective sides.

Rear Light

Safety is a major concern for us. That’s why all M-Class ebikes are equipped with LED rear lights.

These LED lights are powered by the main battery of the ebike.


ELECTRONICS

Battery

48V 12Ah Samsung

Motor

48V 500W Mid-Drive Motor, 98Nm torque

Charger

48V 2Ah Smart Charger with Cell Balancing

Display

Back-lit LCD, with Easy Diagnostics Feature, with USB charging port

Sensor

Torque & Cadence Sensor integrated in Mid-Drive Motor

Front Light

Spanninga 20 Lux

Rear Light

Spanninga

Wiring

Water Resistant

Throttle

Half Twist Throttle


COMPONENTS

Brakes

Tektro Hydraulic disc brakes

Pedals

Wellgo Steel Pedals

Brake Levers

Tektro Hydraulic Disc Brake Levers

Seatpost

Suspension Seatpost

Gears

Shimano Nexus 7-Speed Internal Hub Gears

Shifter

Shimano Twist Shifter

Crankset

38T

Chaincover

Plastic

Derailleur

Nexus Inner Hub

Kickstand

Single Kickstand

Fork

Spring Load Suspension Fork

Stem

Promax Easy Adjustable Stem

Fenders

Front & Rear Mudguards

Spokes

13g Stainless Steel

Frame

AL6061 Double Heat Treated

Rim

20x1.75 Double Walled Rims

Saddle

Velo - Plush

Tires

20x1.75 CST Tires with Reflective Side Walls

Handlebar Grips

Faux Leather, Hand Stitched

Tools

All Assembly Tools and Touch Up Paint Included


SIZING

1 2 3 4

43.3"

17.3"

17.5"

22.5"

Weight: 47.5lbs


Videos & Photos

  • Videos
  • Photos

ACCESSORIES

COMPONENTS

We carefully selected each and every component we put into the M-Class electric commuter bike. Ariel Rider is passionate about electric bikes – our designers, engineers, and even our office staff have all ridden them in our daily commutes for years now. You can trust that we are experienced ebike enthusiasts who understand the expectations and real-world problems electric bike riders face in daily life. We’re proud to ride a fully-featured electric commuter bike that is not only great-looking, but also affordable, boasting the latest technology available.

Customer Reviews

Based on 164 reviews
83%
(136)
16%
(26)
1%
(2)
0%
(0)
0%
(0)
M
M.
Awesome

I drive semi truck and wanted a way to explore so did some research , I've had this bike going on three years and still going strong .
I ditched the fenders and put bigger tires on it . Thing really scoots .its basically the BMX bike I wish I had when I was a kid

H
H.
So far it’s all good news.

Only 40 miles on the bike so far but I love it.

Starting at the beginning, after purchasing the bike there was a bit of a delay confirming the order and shipping but that was followed up with a confirmation and a follow up email.

Bike arrived with some signs it had been jostled around in shipping but no damage occurred. Bike and tubing were very well packaged.

Assembly took about an hour. It should have taken 10 minutes but attaching the front fender was extremely difficult due to the bolts being just a hair not long enough. Technically they are long enough but it’s very awkward and required pre-bending some of the plumber style clamp ends. It was comedically difficult given that it was just putting three bolts into holes. Also required an adjustable wrench that was not included.

A spare parts bag was included and a variety of cheap tools which was very welcome.

After the fender issue I was up an running in no time. There are no physical directions in the box and my phone was dead so I had no way to go online to review the setting options for the display controller but figured out the basic operation.

The bike works exactly as you would expect and I had no problem getting up to 20 miles per hour which is definitely fast enough. The gearing is also very usable without turning on the motor. Obviously geared for hills and start and stop riding not speed. For a city bike that’s the way it should be!

Two negatives. The paint job is fine but not as durable as most mass produced bikes. Not a big deal. Just easy to scratch.

The battery meter shows significantly less mileage in the two highest pedal assist levels. Haven’t had time to accurately compare the mileage in level 1 vs 5 but I’d be surprised if level 5 is 20 miles range on moderately hilly terrain with a 175 lbs rider.

There are bosses to attach a water bottle cage but the location on the top of the top tube would make for awkward mounting and dismounting.

Parts and build quality are very nice. Nothing cheap about this at all. The seat is IMO ugly but not uncomfortable. The rear rack came pre attached. I like that it is not part of the frame if it gets damaged or I just don’t want to use it.

The bike is very compact which was why I selected it. Not much longer than a Brompton but much heavier.

C
C.J.
Light and Nimble

My first impression is that the M-Class is easy to handle, I have to carry my bike upstairs and the weight of my older W-Class was wearing on me. Wondering how well the smaller tires will wear. The front shocks allow more dampening than i thought they would. I’ve only ridden it once so I’d rather get back to you in about a month or two with a better informed review.

V
V.S.
Love my bike

Shipped well. The video for putting the fender on needs to be re-done. Also, putting the fender on was very difficult once we figured out how to put it on.
Great bike easy to ride and very lite weight. I have had a few EBike and this is the best one I have had. I live in The Villages where you ride up and down tunnels, bridges and golf cart paths. Very Smooth ride and fun.

R
R.R.
Great and Terrible

Ariel M Class

WONDERFUL!
packing
box inside of box
both boxes are double thick cardboard
plenty of large staples to make each rectangle box stiff
ALL parts are heavily protected with redundant foam and bubble wrap
ALL parts are secured with redundant ties
Fork assembled on the frame with quality pieces that are discarded to install the handlebar. A frame from another company had the pieces (headset, cap, spacers, stem, etc.) in a box requiring me to assemble the fork onto the frame.
No need to assemble the fork, just discard the above pieces and slide the stem onto the fork with handlebar already installed on the stem.
Tool Kit: more tools than I needed. This is the FIRST bike/frame that I've ordered that included a toolkit. It has redundancies for pleasant usage.
Spare nuts, bolts and washers. Great for adding accessories or preferred sizing.
Rack already installed. Has nuts integrated into the rack which the spare nuts fit.
The seatpost and stem adjusted to the EXACT fit that my custom $10,000 bicycles have.
The ride without the battery was AWESOME. Comfortable and pleasant.
The bicycle stands on end with the installed rear rack.
POWER
With the battery and the assist at 5, you can go everywhere in the highest (7th) gear. I NEVER have to shift and I have a steep hill to climb to get out of my house. I also weigh over 200 pounds.
I need 2nd gear to climb the hill without the battery, but I would probably need 1st gear if I did not go on 50 mile bike (not eBike) rides every other day.
FAST SUPPORT
When contacting support, feedback is provided within a day. . .
NOT SO GREAT
. . . I am very happy with the bike, but I’ve had to make adjustments and adapt to the quirks listed below. . .
The 7 speed hub was out of adjustment and shifted in an unusual fashion on my first ride without the battery. This was an easy adjustment once you search for and watch a video how to. And with the battery pack, I do not need to shift.
TERRIBLE!
NO assembly or operating instructions. YouTube videos are for an older model. On the Ariel website, the picture matches the bike I received. I see a different bike in the video.
Installing the stem is not obvious and the video just shows it being done, but NOT how to do it.
Impossible to install the front fender with the bolts provided. I found some spare bolts that allowed installation. The Ariel website video shows installation onto a different fork.
After requesting assembly and operating instructions from
Ariel, I was sent a link to a PDF. These instructions had several errors and omissions. For example, I had problems installing the front fender. There were NO instructions how to install it.
The operating instructions state a 3 button display, then show 4 buttons.
The website states, “Ariel Rider M-class ships with a 20mph speed limiter. This limit can be changed from the screen up to 25mph.” A video and review (http://ebikereviewer.com/index.php/2018/07/13/ariel-rider-m-class-electric-bike/) shows a max speed of 28 mph, the sticker on the bike states 20 mph, the instructions state to set to 15.5 mph and impossible to set above 25. My bike was shipped with a max speed of 34 mph. I can feel full power past 24 mph while pedaling.
The website states: “This means you'll cruise for days and days without charging it.” However, the instructions state that you need to fully charge before each ride.
The gear system is for 27 inch wheels.
In the highest (7th) gear, you can only pedal comfortably up to about 20 mph, not the 28 mph max shown in the electronics video. Note that 27 inches/20 inches = 1.35 and 28 mph/20 mph = 1.4.
In order for it to be geared for 20 inch wheels, it must have a chainwheel with 1.4x as many teeth.
A standard 52 tooth chainwheel would provide the max 28 mph shown in the electronics video.
Because the 38 tooth chainwheel (optimal for 27 inch wheels) is undersized, you can stay in 7th gear all the time, even up most hills. I leave the assist level at 5.
This means that with the undersized chainwheel, you don't need any gears, a one speed gear in the rear will take care of all situations (provided you don't run out of battery).
Claims to have a torque sensor, however, it is not active. The power is NOT proportional to your efforts. It simply puts out a given power level while you pedal at any effort. My other eBike IS proportional, so you feel feedback; the harder you pedal, you can feel more power going to the wheels. No torque until you apply force to the pedals. On the Ariel M Class, as soon as you pedal, you get FULL torque from the motor proportional to the assist level that you set.
The power fluctuates with constant cadence. 70% up a short hill the power seemed to cut out, then come back on. The same occurred on the way back from the store on a flat road. I have to hold power assistance on for smooth operation. Pedaling allows you to go faster (i.e., adds power).
